Brother TD-2320DSA203 label printer Direct thermal 203 x 203 DPI 152 mm/sec Wired Ethernet LAN
MPN:
Condition:
Couldn't load pickup availability
Key Features
- High quality 203dpi print resolution
- USB & network connectivity (serial connectivity available as optional accessory with PA-SCA-002)
- ZPL 2, EPL 2, DPL printer language emulations
- Built in colour touch screen with keyboard
- 256MB RAM, 64MB Flash
Description
Increasing productivity and reducing costs are key priorities in any workplace. And when it comes to label printing, the TD-2320DSA203 combines proven desktop printer performance with the versatility to operate in multiple locations, helping you to achieve greater efficiencies across your business. The TD-2320DSA203 works as a standalone printing solution with its 3.5" colour touch screen display and keyboard.With a range of specialised features and high-quality print resolutions, the TD-2D is the perfect label printer for retail price mark down labels and food traceability ingredient labels – where you need to print high-quality labels in any location.
Specifications
| Print quality | |
|---|---|
| Maximum resolution | 203 x 203 DPI |
| Maximum printing width | 5.9 cm |
| Printing | |
| Minimum print length | 6.4 mm |
| Colour | No |
| Print speed | 152 mm/sec |
| Maximum resolution | 203 x 203 DPI |
| Maximum printing width | 5.9 cm |
| Print technology | Direct thermal |
| Display | |
| Display diagonal | 8.89 cm (3.5") |
| Colour display | Yes |
| Network | |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Memory | |
| Internal memory | 256 MB |
| Flash memory | 64 MB |
| Paper handling | |
| Media thickness | 0.058 - 0.279 mm |
| Core diameter | 3.81 cm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| USB port | Yes |
| Performance | |
| Built-in barcodes | AZTECCODE, Data Matrix, MSI, CODABAR (NW-7), UPC-A, MaxiCode, Micro QR Code, UPC-E, EAN13, Code 128 (A/B/C), EAN8, POSTNET, Code 39, GS1 DataBar, QR Code, Code 93 |
| Internal memory | 256 MB |
| Flash memory | 64 MB |
| Design | |
| Display diagonal | 8.89 cm (3.5") |
| Colour display | Yes |
| Product colour | Black, Grey |
| Control type | Buttons, Touch |
| Built-in display | Yes |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source type | AC |
| Technical details | |
| Server operating systems supported | Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Windows operating systems supported | Windows 10, Windows 11 |
| Product colour | Black, Grey |
| Built-in barcodes | AZTECCODE, Data Matrix, MSI, CODABAR (NW-7), UPC-A, MaxiCode, Micro QR Code, UPC-E, EAN13, Code 128 (A/B/C), EAN8, POSTNET, Code 39, GS1 DataBar, QR Code, Code 93 |
| Country of origin | Vietnam |
| Products per pallet | 60 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
| Warranty period | 3 year(s) |
| Pallet type | 800 x 1200 mm |
| System requirements | |
| Linux operating systems supported | Yes |
| Server operating systems supported | Windows Server 2016, Windows Server 2019, Windows Server 2022 |
| Windows operating systems supported | Windows 10, Windows 11 |
| Operational conditions | |
| Storage temperature (T-T) | -20 - 60 °C |
| Storage relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 5 - 40 °C |
| Operating relative humidity (H-H) | 20 - 80% |
| Weight & dimensions | |
| Package width | 306 mm |
| Package depth | 181 mm |
| Package height | 325 mm |
| Width | 119 mm |
| Depth | 224 mm |
| Height | 176 mm |
| Weight | 1.77 kg |
| Package weight | 2.9 kg |
| Packaging data | |
| Package width | 306 mm |
| Package depth | 181 mm |
| Package height | 325 mm |
| Package weight | 2.9 kg |
| Packaging content | |
| Cables included | AC, USB |
| Other features | |
| Products per pallet | 60 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
| Country of origin | Vietnam |
| Warranty period | 3 year(s) |
| Spare part retention | 5 year(s) |
| Logistics data | |
| Pallet gross height | 17.5 cm |
| Master (outer) cases per pallet layer | 4 pc(s) |
| Pallet gross weight | 631.2 kg |
| Products per pallet | 60 pc(s) |
| Layers per pallet | 5 pc(s) |
| Master (outer) cases per pallet | 20 pc(s) |
